BharatBenz 1417R

45 reviews

Rate this tractor

BharatBenz 1417R is a powerful tractors comes with an attractive design and features. BharatBenz 1417R comes with a 170 HP powered by undefined and undefined cylinder engine, having a lifting capacity undefined and provides high performance on the field.

Price Coming Soon^*

^*Prices are subjected to change

EMI ₹ 20,362 For 5 YearsEMI Calculator

Key Features of BharatBenz 1417R

Engine
4D34i
Power
170
GVW
14050 KG

Specifications of BharatBenz 1417R

Performance
- Engine Norm
  BS-6 Phase 2
- Engine Cylinders
  4
- GVW
  14050 KG
- Engine
  4D34i
- Fuel Tank
  215 Ltrs.
- Gradeability
  39.2 (%)
- Max Speed
  80 KMPH
- Power
  170
- Max Torque
  520 Nm
Dimensions
- Height
  2475 MM
- Wheelbase
  4250 MM
- Ground Clearance
  220 MM
- Minimum Turning Radius
  16700 MM
- Length
  8030 MM
- Width
  2240 MM
Brakes Suspension
- Brakes
  Pneumatic, Foot operated, Dual line (with ABS)
- Front Axle
  IF 5.0
- Rear Axle
  DANA - S145
- Front Suspension
  Multileaf Spring
- Rear Suspension
  Multileaf Spring
- Parking Brakes
  Spring Actuated with Hand Brake Valve @ Cab
Clutch Transmission
- Steering
  Hydraulic Power Assisted
- Power Steering
  Yes
- Transmission
  Mechanical Sychromesh
- Clutch
  362mm Single Dry Plate, Hydraulic Actuated
- Gearbox
  G85, 6 forward + 1 Reverse
Body Cabin
- Seating Capacity
  Driver + 2 Passenger
- Cabin Type
  Day type Cabin
Tyre
- Front Tyre
  8.25R20 (S), 255/70R22.5 (O)
- Rear Tyre
  8.25R20 (S), 255/70R22.5 (O)
Others
- Seat Belts
  Yes
- Battery
  24 v,75Ah/100Ah (HAP)
